Overview
This portable PLC trainer kit is designed for industrial automation education, vocational training, engineering laboratories, and hands-on PLC learning. It is available with a Siemens S7-1200 or Allen-Bradley Micro850 control platform. Depending on the selected configuration, the system integrates PLC control, touchscreen HMI operation, VFD motor control, industrial Ethernet and RS485 communication, analog signal training, PID control, push buttons, indicator lights, terminal wiring, and practical automation experiments in one compact aluminum training case.
The Siemens configuration is programmed with TIA Portal, while the Allen-Bradley Micro850 configurations use Connected Components Workbench (CCW). All configurations support digital I/O, motor start/stop, forward/reverse control, variable-frequency speed adjustment, analog signal processing, HMI monitoring, communication practice, and basic PID process-control applications.
The portable suitcase-style design makes the system easy to store, carry, demonstrate, and use in classrooms, training centers, workshops, and automation labs.
Key Features
Siemens S7-1200 PLC Training Platform
Designed for learning PLC logic control, I/O wiring, timers, counters, data handling, interlocking circuits, and practical automation programming.
7-Inch Ethernet Touchscreen HMI
The system includes a 7-inch Ethernet touchscreen for HMI operation, parameter display, button control, data monitoring, animation display, and basic visualization training.
VFD Inverter Motor Control
Equipped with a variable-frequency drive and motor training module, this kit supports motor start/stop control, speed adjustment, forward/reverse control, and analog frequency control experiments.
RS485 / Modbus Communication
Supports RS485 communication training and Modbus-based industrial communication practice, helping students understand real-world automation networking.
Analog Signal & PID Control Training
Suitable for analog input/output learning, signal acquisition, temperature or process simulation, and PID control experiments.
Integrated Buttons, Indicators & Terminals
Built-in push buttons, indicator lights, terminals, and wiring modules allow students to practice actual industrial wiring, troubleshooting, and PLC control logic.
Portable Aluminum Training Case
All components are installed inside a durable aluminum case, making it convenient for classroom teaching, mobile demonstrations, laboratory use, and storage.
Training Applications
This PLC training system can be used for:
-
Siemens TIA Portal PLC programming
-
Digital input and output control
-
Timer and counter programming
-
HMI screen design and operation
-
Motor start/stop control
-
Motor forward and reverse control
-
VFD inverter speed control
-
Analog signal acquisition and output
-
PID control experiments
-
RS485 / Modbus communication
-
Button and indicator control
-
Industrial wiring practice
-
Automation troubleshooting training
-
Engineering and mechatronics education
Typical Configuration
-
Siemens S7-1200 series PLC
-
7-inch Ethernet touchscreen HMI
-
VFD inverter and motor training module
-
RS485 communication module
-
Analog signal training module
-
Push buttons and indicator lights
-
Industrial terminals and wiring interface
-
Portable aluminum suitcase-style training case
-
Example training projects for PLC learning
Power Supply
The main training system is configured for 220V power input.
For customers in 110V regions, such as the United States, Canada, and Japan, we will include a suitable 110V-to-220V step-up transformer so the system can be used with local power supply.
Please confirm your local voltage, plug type, and power requirements before ordering.
Recommended For
This PLC trainer kit is suitable for:
-
Universities and colleges
-
Vocational training schools
-
Electrical engineering programs
-
Mechatronics training labs
-
Industrial automation courses
-
PLC programming beginners
-
Factory maintenance training
-
Automation system integrators
-
Technical demonstration projects
Notes
The Siemens version is programmed with TIA Portal. The Allen-Bradley Micro850 versions are programmed with Connected Components Workbench (CCW). HMI and VFD brands follow the selected configuration.
Configuration may vary depending on selected options. Please confirm the PLC model, communication module, analog input/output module, voltage, plug type, transformer requirement, and training documents before placing an order.
Available Configurations
Please select the PLC platform and hardware configuration required for your course.
Siemens S7-1200 Standard – $1,499
Siemens S7-1200 series PLC
7-inch Ethernet touchscreen HMI
Compatible VFD and motor training module
RS485 / Modbus communication and TIA Portal programming
Digital I/O, analog-signal and PID control training
Version A – Allen-Bradley Micro850 with Compatible HMI & VFD – $2,399
Allen-Bradley Micro850 PLC
7-inch Ethernet HMI compatible with the Micro850
Compatible VFD and motor training module
Connected Components Workbench (CCW) programming
Ethernet, RS485 / Modbus, digital I/O, analog-signal and PID training
A cost-effective Allen-Bradley configuration that retains compatible third-party HMI and drive hardware
Version B – Allen-Bradley Micro850 with PanelView 800 & PowerFlex 525 – $3,499
Allen-Bradley Micro850 PLC
Allen-Bradley PanelView 800 7-inch HMI
Allen-Bradley PowerFlex 525 VFD and motor training module
Connected Components Workbench (CCW) programming
EtherNet/IP integration, drive parameter control, HMI visualization, digital I/O, analog-signal and PID training
Recommended for schools that require the PLC, HMI and VFD to use the Allen-Bradley platform
Included in all configurations: portable aluminum training case, push buttons, selector switches, indicator lights, terminal wiring, motor control experiments, analog-signal exercises, example projects and electrical documentation.
Component models and communication functions should be confirmed before ordering. The product images may show the Siemens configuration; the actual components follow the selected configuration.
