Siemens S7-1200 PLC Trainer with KTP700 HMI & SINAMICS V90 Servo

Product Description

Build practical industrial automation skills with a comprehensive PLC training system designed for universities, technical colleges, vocational schools, automation laboratories, and professional training centers.

This higher-education training platform integrates an original Siemens S7-1200 PLC, Siemens KTP700 HMI, and a brand-new Siemens SINAMICS V90 servo system into one structured tabletop workstation. Its modular quick-connect design allows students to complete PLC programming, electrical wiring, HMI configuration, motor control, motion control, sensor integration, and troubleshooting exercises using equipment similar to that found in modern industrial environments.

Core Configuration

• Original Siemens S7-1200 PLC

• Siemens KTP700 SIMATIC HMI touch panel

• Brand-new Siemens SINAMICS V90 servo drive

• Matching Siemens servo motor and encoder cables

• Stepper motor and linear motion module

• Variable frequency drive and AC motor control module

• Digital input and output training terminals

• Analog signal training terminals

• Push buttons, selector switches, indicator lights, and emergency stop

• Industrial relays, contactors, circuit protection, and 24V DC power supply

• Modular aviation-connector quick-connect control system

• Tabletop metal training workstation

Practical Training Functions

The system is designed to support a wide range of industrial automation experiments, including:

• Siemens S7-1200 PLC programming

• Ladder Logic and structured sequence control

• Digital input and output control

• Analog signal acquisition and processing

• Siemens KTP700 HMI screen configuration

• Equipment status monitoring and parameter adjustment

• Alarm display and fault indication

• Stepper motor speed and position control

• Servo positioning and motion control

• Siemens V90 servo parameter configuration

• Variable frequency drive speed control

• Forward and reverse motor operation

• Sensor signal detection and automatic sequence control

• Relay, contactor, and motor control circuits

• Emergency stop and electrical interlocking

• Industrial communication and system integration

• Fault simulation and troubleshooting exercises

Siemens Integrated Automation Platform

The combination of the Siemens S7-1200 PLC, KTP700 HMI, and SINAMICS V90 servo system provides a consistent Siemens-based learning environment.

Students can gain practical experience with:

• PLC hardware configuration

• TIA Portal programming

• HMI visualization

• Servo commissioning

• Motion control

• Industrial networking

• Equipment diagnostics

• Integrated automation projects

This configuration is especially suitable for courses that already use Siemens TIA Portal or plan to introduce Siemens industrial automation technology.

Modular Quick-Connect Design

The aviation-connector interconnection system simplifies equipment setup and module connection while reducing the risk of incorrect internal wiring.

Internal power and control circuits are organized within the workstation, while the front training terminals allow students to complete practical low-voltage wiring exercises.

Benefits include:

• Faster classroom preparation

• Clear module separation

• Convenient equipment maintenance

• Reduced wiring errors

• Easy module replacement

• Suitable for repeated student use

• Convenient transportation and laboratory installation

Designed for Education and Training

Recommended for:

• Electrical Engineering

• Mechatronics Engineering

• Industrial Automation

• Manufacturing Engineering

• Mechanical and Electrical Engineering

• Industrial Maintenance

• PLC Programming Courses

• Motor and Drive Control Courses

• Motion Control Laboratories

• Capstone Design Projects

• Technical and Vocational Education

HMI and Language Options

The Siemens KTP700 HMI can be configured with an English-language interface for international teaching environments.

Typical HMI functions may include:

• System overview

• Manual and automatic modes

• Motor operating status

• Servo position monitoring

• Speed and parameter settings

• Input and output monitoring

• Alarm information

• Equipment diagnostics

Custom HMI pages and bilingual interfaces can be configured according to course requirements.

Power Supply Options

Available power configurations include:

• 120V / 60Hz for the United States and Canada

• 220–240V / 50Hz for Europe and other international markets

The required voltage, frequency, plug type, PLC model, servo control method, and training modules should be confirmed before production.

Recommended Software

• Siemens TIA Portal

• STEP 7

• WinCC

• SINAMICS V-ASSISTANT or compatible Siemens commissioning software, depending on the selected V90 version

Software licenses are not included unless specifically stated in the quotation.

Documentation Options

English-language documentation can be prepared according to the final configuration, including:

• User manual

• Electrical schematic

• Terminal wiring diagram

• I/O allocation table

• Component list

• PLC sample programs

• HMI project files

• Servo parameter settings

• Training exercises

• Instructor reference materials

Please confirm the required documentation package and editable source files before ordering.

Important Configuration Notice

The product is manufactured according to the confirmed order configuration. Component appearance, model numbers, communication methods, and terminal layouts may vary depending on the selected PLC CPU, KTP700 version, V90 servo version, voltage standard, and optional training modules.

Please contact us before ordering to confirm the complete bill of materials and technical requirements.

Power Supply

The training system operates on 220V AC.

For customers in countries using 110–120V power, such as the United States and Canada, a compatible 110–120V to 220V step-up transformer will be included with the equipment.

The transformer will be selected according to the power requirements of the complete system. Please confirm your local voltage, frequency, and plug type before ordering.

• Equipment operating voltage: 220V AC

• Transformer input: 110–120V AC

• Transformer output: 220V AC

• Plug type: Configured according to the destination country
